Description
Benefits
- Produces a smooth casting surface, reducing machining requirements.
- Ensures easy and consistent ejection of castings.
- Suitable for both regular-section and thin-wall castings.
- Helps minimize cold shuts and un-filling defects.
- Provides stable performance during extended production cycles.
- Reduces frequency of die touch-ups and maintenance.
- Improves casting quality and dimensional consistency.
- Enhances die life by providing controlled thermal protection.
Applications
- Low Pressure Die Casting (LPDC)
- Gravity Die Casting (GDC)
- Aluminium alloy wheel manufacturing
- Automotive components
- Thin-wall aluminium castings
- Structural and engineering castings
- Components requiring superior surface finish
Specifications
| Parameter | Details |
|---|---|
| Form | Liquid |
| Color | Off White |
| Base | Water Based |
| Dilution Ratio | Customized as per application |
| Coating Thickness | 80 – 100 Microns |
| Application Method | Spray |
| Drying Method | Air Dry / Heated Die |
| Packaging | 25 Kg Containers |
Recommended Usage
- Clean the die surface thoroughly before application.
- Stir the coating well to achieve a homogeneous mixture.
- Dilute as recommended based on casting geometry and process requirements.
- Apply uniformly using a spray system.
- Allow proper drying before commencing production.
- Perform minor touch-ups only in high-wear areas during extended runs.
- Monitor coating thickness periodically to maintain optimal casting quality.
Recommended for LPDC and GDC operations requiring excellent surface finish, reduced casting defects, and long production stability.
